Byson Static Rail Systems / Kits

Introducing the Byson Modular Sliding Rail Kit for Meat Hanging – an easy-to-install DIY solution for building ceiling-mounted meat hanging systems. Complete DIY Modular Kit This kit comes with: 1x 1m (3.25ft) anodized aluminum channel rail 2x support clamp sets with stop chain. Installed at ends of successive channel rails (ie join points), the support clamps enable the modular approach to connect multiple kits and build longer systems 2x single meat hooks Supports 400-500lb load (evenly distributed) per 2 Support Clamp Sets. Common hardware includes 2 x 5/16 (M8) bolt (length as per site conditions) + nut sets and 4x washers per Support Clamp Set. Channel Rail Anodized finish for superior rust and corrosion resistance, and enhanced aesthetics. Support Clamps Robust mounting of channel rails Meat Hooks Made of heavy duty Stainless Steel, with a Teflon collared channel / rail guide to ensure a smooth sliding motion of the hook through the channel rail. Detailed schematic of a larger Byson Sliding Rail System (for illustration): Installation guidance: On outside roof of cooler, position cross support beams (not provided) perpendicular to main runs of rail Hold rails in place against inside ceiling Installation tips for modular building of larger systems: Ensure tight/snug abutting of adjacent Rail lengths and Bends at join points to promote free sliding of loaded Channel meat Hooks along rail system once installed Ideal for Meat Processing: Perfect for transferring meat from loading areas/kill rooms to walk-in coolers, as well as storage in refrigerated spaces like walk-in coolers, cold rooms, or refrigerated trailers. Suitable for Various Meats: Suitable for hanging and storing beef, goat, lamb, deer, elk, and more, making it an excellent choice for butchers, hunters, and others in the meat industry. Durable Construction: The kit includes a 1-metre anodized aluminium Byson channel rail and two support clamp sets for secure and long-lasting installation. This DIY kit includes a 1-metre anodized aluminum rail, 2 end support clamps with stop chain and 2 single hooks,
